SPECIFICATIONS
Product Category:
TV Ceiling Mount
Rank:
Standard
Material:
Steel
Metal Sheet Thickness:
VESA Panel THK=1.5mm cold-rolled sheet,Wall Plate THK=2mm cold-rolled sheet (VESA Panel THK=0.059″ cold-rolled sheet,Wall Plate THK=0.079″ cold-rolled sheet)
Pipe Size:
30x20x1.5mm Square Steel Tube (1.2″x0.79″x0.059″ Square Steel Tube)
Surface Finish:
Powder Coating
Color:
Fine Texture Black
Dimensions:
614x435x165mm (24.2″x17.1″x6.5″)
Fit Screen Size:
23″-55″
Fit Curved TV:
Yes
Mounting Hole Pattern:
VESA Only
VESA Compatible:
75×75,100×100,100×200,200×100,200×200,200×300,300×200,200×400,400×200,300×300,300×400,400×300,400×400
Max. Mounting Hole:
400×400
Weight Capacity:
20kg (44lbs)
Strength Tested:
3 Times Approved
Profile:
83mm (3.3″)
Tilt Range:
0/-80°
Swivel Range:
+45°~-45°
TV Height Range:
min520~max614mm (min20.5″~max24.2″)
Installation:
Ceiling Mounted
Panel Type:
Detachable Panel
Wall Plate Type:
Fixed Wall Plate
Direction Indicator:
Yes
Cable Management:
No
Bubble Level:
No
Accessory Kit Package:
Normal/Ziplock Polybag,Compartment Polybag
